bocad SmartPointCloud:
Process point clouds directly in bocad
ADDITIONAL MODULE
From 3D laser scanning to precise as-built models, the digital basis for precise construction in existing buildings
Accurate digital as-built data is crucial for renovations, extensions, or complex existing building situations. 3D laser scanning provides a complete image of the actual conditions in the form of a point cloud. With bocad SmartPointCloud, you can import a laser scan into CAD and continue working immediately in your familiar design environment without additional programs and without media discontinuity.
SmartPointCloud enables powerful processing of point clouds directly in bocad. Millions of precise measurement points are available to you as a basis for as-built modeling, collision checking, and custom-fit design.
How can laser scans be imported and processed directly in bocad?
With bocad SmartPointCloud, you can import point clouds from 3D laser scanning directly into your design environment. The captured measurement points are immediately available for modeling, dimensioning, and collision checking.
Bildreferenz:
Schultheis Stahlbau GmbH
Kontaktieren Sie uns, wir beraten Sie gerne.
Point clouds from 3D laser scanning are particularly suitable for:
-
Conversion and renovation projects in existing buildings
-
Extensions to existing structures
-
Connections to existing supporting structures
-
Integration of new components into existing structures
-
Collision checks in complex installation situations
-
Digital as-built documentation in building and industrial construction
Especially in cross-trade projects, the direct import of laser scans creates a reliable basis for planning.
Technical features of bocad
SmartPointCloud
-
Support for common point cloud formats from 3D laser scanning
-
Direct import of laser scans into bocad
-
Powerful processing of large amounts of data
-
Precise navigation, cutting, and measurement functions
-
Integration into existing projects
-
Support for BIM-oriented work processes
How does the scan-to-BIM workflow work with bocad?
With bocad SmartPointCloud, you can seamlessly integrate 3D laser scans into your project workflow:
-
Capture existing structures using 3D laser scanning
-
Import point cloud into bocad
-
Derive 3D inventory models or design directly in the model
-
Compare virtual planning with the actual situation
The point cloud serves as a precise reference for design, dimensioning, and collision control.
